Model No: Ground-mounted PV Bracket
Ground-mounted PV Bracket
This ground‑mounted PV bracket system is engineered for open‑field solar power plants. Constructed from high‑strength 6005‑T5 anodized aluminum alloy and stainless steel fasteners, it delivers outstanding structural stability and anti‑corrosion performance for long‑term outdoor service. Compatible with our PW‑series sliding rails, the modular design supports flexible angle adjustment and adapts to various terrain conditions. Pre‑fabricated components greatly cut field‑installation time, making it a robust solution for utility‑scale and commercial ground solar projects.
Quantity :
| Component Name | Material | Performance | Application Scenarios |
| C-channel | Aluminum Profile / Zinc-Aluminum-Magnesium / Hot-Dip Galvanized Steel | High bending strength, anti-corrosion, excellent load-bearing performance | Main purlin & beam member for ground PV support system, carries solar panel loads |
| Galvanized Steel Pipe Pile | Hot-dip galvanized steel | High compressive & pull-out resistance, anti-rust, stable foundation performance | Driven into ground as the foundational support for the whole bracket structure |
| Triangle Connector | Hot-dip galvanized steel / aluminum alloy | High structural rigidity, anti-deformation, stable corner connection | Reinforces frame corner joints to improve overall bracket stability |
| End Clamp | Anodized aluminum profile | Insulating, anti-slip, reliable clamping force | Fastens the outer edge of PV modules on mounting rails |
| Mid Clamp | Anodized aluminum profile | Uniform clamping pressure, corrosion-resistant | Secures the splicing position between two adjacent solar modules |
| Purlin Connector | Hot-dip galvanized steel | High splicing strength, anti-aging | Connects separate C-channel purlins to extend overall length |
| Pipe Clamp | Hot-dip galvanized steel | Strong holding force, anti-loosening | Fastens round tubes / pipe piles with other structural parts |
| Purlin Support | Hot-dip galvanized steel | High bearing capacity, stress dispersion | Support fitting for fixing purlins onto vertical uprights |
| Straight Tie Connector | Hot-dip galvanized steel | High tensile strength, tension-resistant | Connects straight ties to form bracing system against wind & snow deformation |
| Galvanized Round Tube | Hot-dip galvanized steel | Good structural toughness, long anti-corrosion life | Used as vertical posts, cross braces and auxiliary support bars |
| Straight Tie | Hot-dip galvanized steel | High tensile property, anti-distortion | Horizontal/diagonal bracing member to stabilize the whole framework |
| Hex Head Bolt | High-strength hot-dip galvanized carbon steel | Superior fastening force, anti-loosening | Universal standard fastener for assembling all bracket components |
